Building Specification

External

  • Existing brick walls laid in Flemish bond, pointed with lime mortar
  • New external boardwalk overlooking river with new natural stone finish
  • High performance clear glass balustrade flood defence of laminated safety glass and stainless steel upstands
  • New electric automated, sliding doors of European Oak with accoya rails and stiles finished with natural Danish oil and anti graffiti treatment
  • Natural blue Bangor slates re-used from existing roof, and sourced salvaged natural slates to match existing.
  • TB50SG Curtain Wall System with flush glazing and double glazed doors
  • Feature circular double glazed Bullseye window to eastern and western gables
  • Repaired steel frames to high level windows with new glazing
  • New continuous frameless clerestory panoramic strip window with double glazed units
  • Apex rooflights with opening vents for natural ventilation, electronically automated with rain sensors.

Internal

Ground Floor



  • New raised access floor with 200mm void on screed on insulated reinforced concrete slab on ground beams and piles
  • 600 x 600mm raised access floor from Kingspan, RMG600 medium grade
  • New internal wall surrounding new stair - varying widths American White Oak planks to outside face
  • Exposed existing brick walls and feature painted finned timber walls
  • New salvaged imperial brick wall with laid in English garden wall bond with lime pointing
  • Steel stairs clad with European oak risers and treads
  • Vogue ceramica wall tiles, 100 x 200mm to bathrooms with 200 x 200 Vogue tiles to floor with ceramic oak plank border
  • Calacatta marble vanity units with mitred cornered edges
  • Catalano and Laufen sanitaryware with Hansgrohe taps
  • Geberit wc concealed system and Geberit floor drains, with brushed stainless steel flush grating
  • Electric Aquilsa Lumi power showers
  • Klaro electric towel radiators with chrome finish
  • External walls are solid brick walls, Flemish bonded, with lime mortar. The exposed brick continues to the interior walls of the office. Granite quoin stones feature to all large openings to street. Internal salavaged brick walls feature at ground floor level. Other walls panelled with plasterboard lightweight partitions and hardwood panelled featured walls.

Mezzanine Floor



  • High grade European Oak floorboards with white oiled finish
  • Cantilevered clear glass balustrades to mezzanine double height spaces
  • Stainless steel cill boards and details to panoramic strip windows
  • New painted plasterboard finish to inside face of new stud wall

Building Services

  • Separate metered water mains connection
  • Independent drainage system
  • Rainwater harvesting tank supplying external taps
  • Separate and metered Electricity supply – 3 Phase and 100 amp supply
  • Fire detection, alarm and automatic opening vent to rooflight with fire panel supplied and fitted
  • Full heat recovery ducted air system installed throughout
  • Full air conditioned system installed throughout operated from newly installed air to water heat pumps
  • New electrical cabling and cat 6 cabling provided throughout including floor mounted outlets to mezzanine
